You're right — here's the revised version with bullet points included for clarity, while keeping it all in one complete block as requested:Easily clone your existing remote controls with this versatile 433.92MHz remote duplicator.
Designed for garage doors, electric gates, car alarms, and more, this compact 4-channel key fob supports fixed codes, learning codes, and limited rolling code systems. It's compatible with a wide range of IC models and offers strong signal transmission up to 100 meters in open areas.
SPECIFICATIONS
- Model: 433MHz Garage Remote Control
- Frequency: 433MHz / 433.92MHz
- Encoding Method: Learning code, Rolling code (limited), Fixed code
- Supported ICs: 2260, 2262, 2240, 1527, FP527, HT600 series, SMC918, HT12D, PIC16F629, PIC16F630, and more
- Working Current: 10mA
- Radiation Power: 10mW
- Transmission Distance: 50–100m (open area)
- Battery Type: 27A 12V (included)
- Weight: 28g
- Size: 5.4 × 2.9 × 1.4 cm
- Certification: CE
- Origin: Mainland China
- High-Concern Chemicals: None
FEATURES
- Clone up to 4 remote control signals, each button stores a separate code
- Compatible with dozens of common IC models across various remote systems
- Simple programming process with LED confirmation
- Code clear and restore functions make setup easy and reversible
- Long-range performance up to 100 meters in open spaces
- Compact, keychain-ready design with a durable ABS shell
- Multi-use application for garages, gates, alarms, lights, and more
INSTRUCTIONS
-
To Clear Codes:
- Press the top two buttons together (lock + unlock).
- When the LED flashes 3 times, release one button.
- Press the other button 3 times.
- LED will flash quickly — clearing complete. If no LED lights up after, the code is cleared.
-
To Copy Codes:
- Place the original and duplicator remotes side-by-side.
- Hold matching buttons on both until the LED flashes quickly after 3 slow blinks.
- Release to confirm success. Repeat for other buttons.
-
To Recover a Code:
-
Press buttons 3 and 4 at the same time until the LED flashes 3 times — recovery successful.
-
APPLICATIONS
- Electric garage doors
- Sliding or swing gates
- Vehicle alarms
- LED lighting systems
- Electric locks or shutters
- Any 433MHz RF device using fixed or learning code
PACKAGE INCLUDES
-
1 × 433MHz 4-Button Remote Control (with battery)
Note: Rolling code compatibility is limited and cannot be guaranteed due to encryption used in some remote types. Best results occur with fixed and learning code systems.
